Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

ABB

ABB Blackburn, AL12, 4/0 AWG, 2-Hole, Compression Lug, Aluminum/Copper

Out of stock
SKU: AL12 UPC: 783786047284
(0)
$14.95
-51% $30.25 $14.95
Out of stock
Condition

AL12 specifications

  • Manufacturer: ABB (formerly Thomas & Betts)
  • Brand: Blackburn
  • Product Range: AL Series (Aluminum Two-Hole Compression Lugs)
  • UPC: 783786047284
  • Model Number: AL12
  • Connector Type: Aluminum Two-Hole Compression Lug, Straight Long Barrel, Blind-End
  • Conductor Material: Aluminum and Copper
  • Cable Size: 4/0 ASCR AWG; 4/0 Stranded AWG
  • Connection Type: Compression
  • Bolt Size: 1/2 in
  • Mounting Type: NEMA Standard Mounting Holes (2-Hole)
  • Material: Aluminum (Tin Plated)
  • Mechanical Dies: 840, K840, 845, TX
  • Hydraulic Dies: 840, B49EA, EEI, 11A, K840, 249, 76, CSA 24
  • Special Features: Pre-filled with oxide-inhibiting compound; die and crimp information indented on lug
  • Dimensions: Length: 6.13 in; Width: 4.81 in; Depth: 7.1 in (package)
  • Certifications: UL Listed, CSA Certified

This ABB Blackburn AL12 aluminum two-hole compression lug delivers reliable 4/0 AWG connections for aluminum and copper conductors. Featuring a straight long barrel, blind-end design, and NEMA-standard 2-hole mounting with 1/2 in bolt size, it suits industrial and commercial electrical termination applications.
