Eaton BQ, BQ230230, 30A/30A, 2P/2P, 120/240V, Quadplex, Circuit Breaker

Out of stock
SKU: BQ230230 UPC: 786676371001
(0)
$36.00
-25% $48.00 $36.00
Out of stock
Condition

BQ230230 specifications

  • Manufacturer: Eaton
  • Brand: Eaton
  • Product Range: BQ (for Type BR loadcenters and residential panels)
  • UPC: 786676371001
  • Model Number: BQ230230
  • Breaker Type: Quadplex Thermal Magnetic Circuit Breaker
  • Amperage: (2) Two-Pole 30 Amp
  • Poles: 4-Pole, configured as (2) 2-Pole circuits
  • Voltage: 120/240 Volts AC
  • Interrupt Rating: 10 kAIC
  • Mounting Mode: Plug-in
  • Connections Terminals: Pressure Plate
  • Wire Size: #14-4 AWG Cu/Al
  • Dimensions: Height: 3.10 in; Width: 3.20 in; Depth: 1.40 in
  • Weight: 2.50 lbs
  • Certifications: UL Listed, HACR Rated
  • Special Features: CTL rejection tab feature

This Eaton BQ230230 quadplex breaker combines two 2-pole 30 Amp breakers in a compact design for 120/240V circuits in Type BR loadcenters. Designed for plug-in installation with 10kA interrupt rating and CTL rejection tab feature, it supports space-saving residential panel applications.
