Eaton BRD, BRDC220220, 20A, 4P, 120/240V, Quadplex, Plug-On, Non-CTL, Circuit Breaker

Out of stock
SKU: BRDC220220 UPC: 786676007788
(0)
$32.00
-36% $50.00 $32.00
Out of stock
Condition

Eaton BRDC220220: 20 Amp, 4-Pole, Type BRD Quadplex Circuit Breaker, 120/240V, 10kA, Plug-On, Common Trip, Non-CTL, UL Listed.

  • Manufacturer: Eaton
  • Brand: Eaton (Cutler-Hammer)
  • Product Range: BRD (Type BR 1-Inch Quadplex — for Eaton Type BR load centers)
  • UPC: 786676007788
  • Model Number: BRDC220220
  • Breaker Type: Thermal Magnetic Quadplex Circuit Breaker, Common Trip — Non-CTL (No Rejection Tab)
  • Configuration: (2) 2-Pole 20A outer independent trip circuits + (2) 2-Pole 20A center independent trip circuits
  • Amperage: 20 Amps (all poles)
  • Poles: 4-Pole (Quadplex)
  • Voltage: 120/240 Volts AC
  • Interrupt Rating: 10 kAIC
  • Number of Spaces: 2
  • Mounting Mode: Plug-on
  • Wire Size: #14–4 AWG Cu/Al
  • Dimensions: Height: 2.9 in; Width: 2.0 in; Depth: 2.9 in
  • Weight: 0.77 lbs
  • Certifications: UL 489, CSA Certified, HACR Rated, Federal Specifications Classification W-C375

This Eaton BRDC220220 quadplex circuit breaker delivers dependable 20 Amp, 4-Pole protection for 120/240V circuits in Eaton Type BR load centers. Combining two independent 2-pole 20A circuits in a compact 2-space footprint without a rejection tab, it supports residential space-saving distribution applications with 10kAIC interrupt capacity.
