Eaton CCV2200 200A 2-Pole 120/240V Tenant Main Breaker for Type ECC Enclosures

In stock
SKU: CCV2200 UPC: 786685368573
(0)
$125.00
-46% $230.00 $125.00
In stock
Usually ships within 24 hours
Condition

CCV2200 is a 200A Eaton tenant-main breaker for Type ECC unit enclosures. Eaton specifies two poles, 120/240V AC, and a 10 kAIC interrupting rating, with large Cu/Al conductor capacity for the intended service equipment.

CCV2200 specifications

  • Catalog number: CCV2200
  • Device class: Tenant main breaker
  • Frame / use: CCV for Type ECC unit enclosures
  • Rating: 200A, 2 pole, 120/240V AC
  • Interrupt rating: 10 kAIC
  • Accepted wire range: #2/0 AWG–300 kcmil Cu/Al
  • Certification: UL 489

This is enclosure-specific equipment

CCV2200 is not a general-purpose 200A branch breaker and should not be treated as interchangeable with every Eaton main. Its frame, terminals, enclosure listing, available-fault-current rating, and conductor range all form part of the selection.

Service-equipment review required

Confirm the exact Type ECC enclosure, catalog drawings, 120/240V system, 200A rating, fault-current calculation, and conductor material and size. Torque and installation details must come from the current Eaton instructions. Selection and work on service equipment should be handled by a properly qualified electrical professional.
