Eaton CH, CHN230SUR, 30A, 2P, 120/240V, Surge Breaker, Pigtail Neutral

Out of stock
SKU: CHN230SUR UPC: 786689217174
(0)
$115.00
-4% $120.00 $115.00
Out of stock
Condition

CHN230SUR specifications

  • Manufacturer: Eaton
  • Brand: CH
  • Product Range: CH (for Eaton Type CH loadcenters and residential panels)
  • UPC: 786689217174
  • Model Number: CHN230SUR
  • Breaker Type: Residential Surge Breaker
  • Amperage: 30 Amps
  • Poles: 2-Pole
  • Voltage: 120/240 Volts AC
  • Interrupt Rating: 10 kAIC
  • Mounting Mode: Plug-in
  • Connections Terminals: Pigtail Neutral
  • Wire Size: #14-4 AWG Cu/Al
  • Dimensions: Height: 2.25 in; Width: 6 in; Depth: 3.5 in
  • Weight: 0.6 lbs
  • Nominal Discharge Current: 10 kA
  • Surge Current Capacity: 36 kA per phase
  • Certifications: UL 489 Listed, UL 1449 Listed

This Eaton CHN230SUR pigtail neutral surge breaker provides reliable 30 Amp, 2-Pole whole-home surge protection for 120/240V circuits in CH loadcenters. With 36 kA surge current capacity and 10 kA nominal discharge rating, it ensures enhanced protection for residential applications against damaging power surges from lightning and utility grid switching.

There is a $15 charge for delivery. Additional charges will be imposed by our couriers for delivery to remote areas, a surcharge may be levied to cover carriage to these areas.

Warranty Coverage

We stand behind every product we sell. Coverage depends on the condition of the item at time of purchase:

  • New: 12-month warranty
  • New Open Box: 10-month warranty
  • Reconditioned: 90-day warranty

Warranty coverage begins on the date of delivery and covers manufacturing and functional defects under normal use. It does not cover damage from misuse, improper installation, or unauthorized repair. To make a warranty claim, contact us at support@breakersmart.com with your order number and a description of the issue.
