Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

Eaton

Eaton GHB3015 15A 3P 480V G-Frame Molded Case Circuit Breaker

SKU: GHB3015
(0)
$237.50
-26% $320.00 $237.50
Out of stock
Condition

Eaton GHB3015: 15 Amp Three-Pole Molded Case Circuit Breaker, G-Frame, 480Y/277V, 65kAIC, Fixed Thermal/Magnetic Trip

Product Specifications

  • Manufacturer: Eaton
  • Model Number: GHB3015
  • UPC: 786679911259
  • Product Type: Series C Molded Case Circuit Breaker
  • Circuit Breaker Frame: G-Frame
  • Breaker Type: GHB Complete Breaker
  • Amperage Rating: 15 Amps
  • Poles: Three-Pole
  • Voltage Rating:
    • 480Y/277V AC
    • 125/250V DC
  • Frequency: 50/60 Hz
  • Interrupt Rating:
    • 65 kAIC at 240V AC
    • 14 kAIC at 480Y/277V AC
  • Trip Type: Fixed Thermal, Fixed Magnetic (T186)
  • Dimensions:
    • Length/Depth: 2.63 in
    • Height: 4 in
    • Width: 3 in
  • Weight: 1.75 lb
