Eaton

Eaton HFD3100 100A 3-Pole 600V Molded Case Circuit Breaker

Out of stock
SKU: HFD3100 UPC: 786679175897
(0)
$500.00
-20% $625.00 $500.00
Out of stock
Condition

HFD3100 fault-rating correction: Eaton HFD3100 is a complete Series C F-frame breaker rated 100 amps with fixed thermal and magnetic trip elements. Eaton lists substantially higher voltage-specific interrupting ratings than the former 18kA description.

HFD3100 specifications

  • Catalog number: HFD3100
  • Rating: 100A, 3-pole
  • Voltage: 600VAC / 250VDC
  • Interrupting capacity: 100kAIC at 240VAC; 65kAIC at 480VAC
  • Frame: Series C F-frame, HFD
  • Trip: Fixed thermal, fixed magnetic

Maximum voltage is not the AIC test voltage

A 600VAC maximum rating does not mean the published 65kA value applies at 600 volts. The applicable interrupting capacity must be taken from the nameplate and Eaton table for the actual system.

System match

Confirm line/load terminals, mounting hardware, voltage, available fault current, accessory wiring, and coordination. Qualified electrical personnel should select and install the breaker under the equipment manufacturer's procedures.
