Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

Eaton

Eaton QB, QBHW3020H, 20A, 3P, 240V, 22kAIC, Bolt-On, Circuit Breaker

Out of stock
SKU: QBHW3020H UPC: 786679393208
(0)
$65.00
-32% $95.00 $65.00
Out of stock
Condition

QBHW3020H specifications

  • Manufacturer: Eaton
  • Brand: Eaton (Cutler-Hammer)
  • Product Range: QB – Quicklag (for Eaton Pow-R-Line QB-style panelboards and industrial applications)
  • UPC: 786679393307
  • Model Number: QBHW3020H
  • Breaker Type: Thermal Magnetic Quicklag Industrial Circuit Breaker
  • Amperage: 20 Amps
  • Poles: 3-Pole
  • Voltage: 120/240 Volts AC
  • Interrupt Rating: 22 kAIC
  • Mounting Mode: Bolt-on
  • Trip Type: Non-Interchangeable (LI — Long-Time and Instantaneous)
  • Wire Size: #14–4 AWG Cu/Al
  • Calibration Temperature: 40°C
  • Dimensions: Height: 4.7 in; Width: 3.8 in; Depth: 3.2 in
  • Weight: 1.1 lbs
  • Certifications: UL 489, CSA Certified, HACR Rated

This Eaton QBHW3020H bolt-on Quicklag industrial circuit breaker delivers dependable 30 Amp, 3-Pole thermal magnetic protection for 120/240V circuits in Eaton Pow-R-Line QB-style panelboards. With 22 kAIC interrupt rating and HACR rating, it supports commercial and industrial distribution applications.

There is a $15 charge for delivery. Additional charges will be imposed by our couriers for delivery to remote areas, a surcharge may be levied to cover carriage to these areas.

Warranty Coverage

We stand behind every product we sell. Coverage depends on the condition of the item at time of purchase:

  • New: 12-month warranty
  • New Open Box: 10-month warranty
  • Reconditioned: 90-day warranty

Warranty coverage begins on the date of delivery and covers manufacturing and functional defects under normal use. It does not cover damage from misuse, improper installation, or unauthorized repair. To make a warranty claim, contact us at support@breakersmart.com with your order number and a description of the issue.
