Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

Eaton

Eaton QB1020GF, 20A, 120/240V, 1-Pole GFCI Circuit Breaker, 5mA Trip, Bolt-On, for QB Load Centers

Only 4 left
SKU: QB1020GF UPC: 786680222498
(0)
$160.00
Only 4 left
Low inventory - Hurry up!
Condition

QB1020GF protection and fit: Eaton QB1020GF is a bolt-on ground-fault breaker for one 20-amp circuit. Its QB frame and 10kA interrupting rating distinguish it from the higher-rated QBH version and from plug-on residential breaker families.

QB1020GF specifications

  • Catalog number: QB1020GF
  • Current and poles: 20A, single-pole
  • Voltage class: 120/240VAC
  • Ground-fault trip: 5mA
  • Interrupting rating: 10kAIC
  • Connection: QB bolt-on

QB versus QBH

QBH1020GF carries a 22kA rating, while this QB1020GF is rated 10kA. They should not be interchanged where the available fault-current calculation or panel listing calls for the higher-rated model.

Installation review

Confirm the panel label, system voltage, ground-fault requirement, conductor range, bolt-on hardware, and terminal torque. This GFCI does not provide AFCI protection. A qualified person should install it on de-energized equipment and perform the manufacturer's functional test.
