Disclaimer: Actual product colors may vary slightly from the images shown due to different monitor settings and lighting conditions during photo shoots.

Siemens

Siemens BQCH1B020, 20A, 1P, 120/277V, Bolt-On, Circuit Breaker

Out of stock
SKU: BQCH1B020 UPC: 783643274709
(0)
$9.00
-61% $23.00 $9.00
Out of stock
Condition

Siemens BQCH1B020: 20 Amp, 1-Pole, Standard thermal magnetic circuit breaker, 120/277V, 65kA@120V, bolt-on, HACR rated, UL listed, CSA.

  • Manufacturer: Siemens
  • Brand: Siemens
  • Product Range: BQCH (for Siemens P1, P2, and P3 panelboards)
  • Model Number: BQCH1B020
  • Breaker Type: Standard Thermal Magnetic Circuit Breaker
  • Amperage: 20 Amps
  • Poles: 1-Pole
  • Voltage: 120/277 Volts AC
  • Interrupt Rating: 65 kAIC @ 120VAC; 14 kAIC @ 277VAC
  • Mounting Mode: Bolt-on
  • Wire Size: #14–6 AWG Cu, #12–6 AWG Al
  • Certifications: UL Listed, CSA, HACR Rated, HID Rated, SWD Rated

This Siemens BQCH1B020 thermal magnetic circuit breaker delivers dependable 20 Amp, 1-Pole protection for 120/277V circuits in BQCH panelboards. Designed for bolt-on installation with 65kA interrupt rating at 120V, it supports commercial and industrial applications.
