Square D EDB14020 20A 1P 277V Thermal-Magnetic Circuit Breaker

In stock
SKU: EDB14020 UPC: 785901878902
(0)
$30.00
In stock
Usually ships within 24 hours
Condition

EDB14020 is a 20A, one-pole E-Frame breaker for Square D NF panelboards. It operates on a 277V AC circuit, bolts to the panelboard bus, and carries a manufacturer-stated interrupting rating of up to 25 kA depending on system voltage.

EDB14020 specifications

  • Catalog reference: EDB14020
  • Series: Square D E-Frame
  • Panelboard use: NF
  • Rating: 20A, 1 pole, 277V AC
  • Trip technology: Thermal-magnetic
  • Interrupt rating: 25 kA maximum; voltage-dependent
  • Mounting: Bolt-on
  • Feature: Visi-Trip indication
  • Compliance: TAA

Why only selection-grade facts remain

The former copy mixed useful nameplate data with unexplained instantaneous-trip and holding-current numbers. Those values are not presented here as branch-circuit selection criteria. The model, voltage, pole count, mounting, panelboard family, and applicable interrupt rating are the facts to reconcile first.

NF panelboard engineering check

Confirm EDB14020 is listed for the exact NF interior and that the 277V circuit, 20A conductor and load design, and available fault current fit the breaker ratings. Review terminal wire range and torque in Schneider Electric’s current instructions. Bolt-on installation and energized-equipment work require a qualified professional.
