Square D Homeline HOM2125 125A 2P 120/240V Standard Plug-In Circuit Breaker

Out of stock
SKU: HOM2125 UPC: 785901065791
(0)
$105.00
-13% $120.00 $105.00
Out of stock
Condition

Square D HOM2125: 125 Amp 2-Pole Standard Circuit Breaker, 120/240V, 10kA, plug-in, UL listed.

  • Manufacturer: Schneider Electric
  • Brand: Square D
  • Product Range: Homeline (for Square D Homeline loadcenters and equipment)
  • UPC: 785901065791
  • Model Number: HOM2125
  • Breaker Type: Standard
  • Amperage: 125 Amps
  • Poles: 2-Pole
  • Voltage: 120/240 Volts AC
  • Interrupt Rating: 10 kAIC
  • Mounting Mode: Plug-in
  • Connections Terminals: Box lugs
  • Wire Size: (1) #4-2/0 AWG Cu/Al
  • Tightening Torque: 42.5 lb-in
  • Dimensions: Height: 3.13 in; Width: 2.0 in; Depth: 2.98 in
  • Weight: 0.860 lbs
  • Certifications: UL Listed, HACR Rated

This Square D HOM2125 plug-in circuit breaker provides reliable 125A, 2-pole standard protection for 120/240V circuits in Homeline loadcenters. Engineered for fast installation and superior circuit protection, it ensures safety and compatibility for residential and commercial applications.

There is a $15 charge for delivery under $250 orders. Additional charges will be imposed by our couriers for delivery to remote areas, a surcharge may be levied to cover carriage to these areas.

Warranty Coverage

We stand behind every product we sell. Coverage depends on the condition of the item at time of purchase:

  • New: 12-month warranty
  • New Open Box: 10-month warranty
  • Reconditioned: 90-day warranty

Warranty coverage begins on the date of delivery and covers manufacturing and functional defects under normal use. It does not cover damage from misuse, improper installation, or unauthorized repair. To make a warranty claim, contact us at support@breakersmart.com with your order number and a description of the issue.
