Square D

Square D Homeline HOM245 45A 2P 120/240V Standard Plug-In Circuit Breaker

In stock
SKU: HOM245 UPC: 785901065500
(0)
$11.50
-18% $14.00 $11.50
In stock
Usually ships within 24 hours
Condition

HOM245 is Square D’s standard 45A two-pole Homeline breaker. It is rated for 120/240V AC, carries a 10 kA interrupting capacity, and plugs into Homeline equipment that lists this breaker type.

HOM245 specifications

  • Model number: HOM245
  • Family: Square D Homeline
  • Breaker type: Standard thermal-magnetic
  • Rating: 45A, 2 pole, 120/240V AC
  • Interrupt rating: 10 kA AIR
  • Installation: Plug-in
  • Certification: UL Listed
  • Electronic fault functions: None

Why 45A must remain an exact match

HOM245 is not a 40A or 50A substitute and should not be upsized or downsized by convenience. It also does not provide AFCI or GFCI protection. The unusual 45A handle rating is part of the load, conductor, and equipment design that must be preserved or recalculated.

Panel and ampacity confirmation

Verify HOM245 is permitted by the loadcenter label and that a two-pole 45A breaker is required for the connected equipment and conductors. Confirm 120/240V and 10 kA suitability. A qualified person should review the load instructions and install the breaker.
