Square D QO, QO260VH, 60A, 2P, 120/240V, Standard, Circuit Breaker

Out of stock
SKU: QO260VH UPC: 78590105497
(0)
$28.00
-26% $38.00 $28.00
Out of stock
Condition

Square D QO260VH: 60 Amp, 2-Pole, Thermal Magnetic circuit breaker, 120/240V, 22kA interrupt, plug-in mounting, UL Listed, CSA Certified.

  • Manufacturer: Schneider Electric
  • Brand: Square D
  • Product Range: QO (for Square D QO load centers, NQ/NQOD panelboards, and Speed-D switchboard distribution panels)
  • UPC: 785901054979
  • Model Number: QO260VH
  • Breaker Type: Thermal Magnetic Miniature Circuit Breaker
  • Amperage: 60 Amps
  • Poles: 2-Pole
  • Voltage: 120/240 Volts AC
  • Interrupt Rating: 22 kAIC
  • Mounting Mode: Plug-in
  • Connections Terminals: Box Lug
  • Wire Size: #8–2 AWG Cu/Al
  • Tightening Torque: 44.25 lb-in
  • Dimensions: Height: 3.12 in; Width: 1.5 in; Depth: 2.91 in
  • Weight: 0.701 lbs
  • Certifications: UL Listed, CSA Certified, HACR Rated

This Square D QO260VH thermal magnetic circuit breaker delivers dependable 60 Amp, 2-Pole protection for 120/240V circuits in QO load centers and NQ/NQOD panelboards. With 22kA interrupt capacity and plug-in installation, it supports residential and light commercial applications.
