Square D QO QO120DF 20A 1P 120V AFCI/GFCI Circuit Breaker

In stock
SKU: QO120DF UPC: 785901401629
(0)
$70.00
-13% $80.00 $70.00
In stock
Usually ships within 24 hours
Condition

QO120DF specifications

  • Manufacturer: Schneider Electric
  • Brand: Square D
  • Product Range: QO (for Square D QO load centers and equipment)
  • UPC: 785901401629
  • Model Number: QO120DF
  • Breaker Type: Combination Arc-Fault and Ground-Fault Circuit Breaker
  • Amperage: 20 Amps
  • Poles: 1-Pole
  • Voltage: 120 Volts AC
  • Interrupt Rating: 10kA
  • Mounting Mode: Plug-In
  • Connections Terminals: Pigtail Neutral
  • Ground Fault Protection: Class A, 6 mA
  • Wire Size: AWG 14 to AWG 8 (copper or aluminum)
  • Tightening Torque: 35.4 lbf.in (4 N.m)
  • Dimensions: Height: 4.8 in; Width: 0.7 in; Depth: 2.9 in
  • Weight: 0.600 lbs
  • Certifications: UL Listed, CSA Certified

This Square D QO120DF combination arc-fault and ground-fault circuit breaker provides dual AFCI/GFCI protection for 20A, 120V circuits, featuring a pigtail neutral design for specific installations. With a 10kA interrupt rating and 6 mA ground-fault protection, it’s ideal for residential settings requiring advanced safety and compatibility with QO load centers.

There is a $15 charge for delivery. Additional charges will be imposed by our couriers for delivery to remote areas, a surcharge may be levied to cover carriage to these areas.

Warranty Coverage

We stand behind every product we sell. Coverage depends on the condition of the item at time of purchase:

  • New: 12-month warranty
  • New Open Box: 10-month warranty
  • Reconditioned: 90-day warranty

Warranty coverage begins on the date of delivery and covers manufacturing and functional defects under normal use. It does not cover damage from misuse, improper installation, or unauthorized repair. To make a warranty claim, contact us at support@breakersmart.com with your order number and a description of the issue.
