Square D

Square D QOM2200VH 200A 2P 120/240V Main Circuit Breaker

SKU: QOM2200VH
(0)
$94.95
-37% $150.00 $94.95
Out of stock
Condition

Square D QOM2200VH 200 Amp, 2-Pole, 120/240 Volt Main Circuit Breaker, standard trip, 22kA interrupt rating, bolt-on mounting for QO or Homeline load centers.

  • Manufacturer: Schneider Electric
  • Brand: Square D
  • Model Number: QOM2200VH
  • UPC: 785901004066
  • Product Type: Main Circuit Breaker
  • Series/Range: QO
  • Protection Type: Standard Trip
  • Amperage Rating: 200 Amp
  • Voltage Rating: 120/240 Volt
  • Number of Poles: 2
  • Interrupt Rating (kAIC): 22 kAIC
  • Mounting Type: Bolt-On
  • Compatibility: QO and Homeline load centers
  • Dimensions (L×W×H, inches): 5.08 × 3.60 × 5.60
  • Weight (lbs): 2.568
  • Certifications: UL Listed, CSA Certified
  • Frame Size: QOM2
  • Ambient Rating: 104 °F (40 °C)
  • Wire Size: 4 AWG – 300 kcmil (Al/Cu)
  • Tightening Torque: 53.1 lbf.in

There is a $15 charge for delivery under $250 orders. Additional charges will be imposed by our couriers for delivery to remote areas, a surcharge may be levied to cover carriage to these areas.

Your product is covered by a 12 month Warranty or more if you opted for the extended warranty. Make sure you register your product.
