Wiremold, 500/700 Series, 5748SWH, 1-Gang, Shallow, Steel, Raceway Device Box, White

Out of stock
SKU: 5748SWH UPC: 786776563016
(0)
$7.00
-52% $14.60 $7.00
Out of stock
Condition

5748SWH specifications

  • Manufacturer: Legrand (Wiremold)
  • Brand: Wiremold
  • Product Range: 500/700 Series (for V500, V700, 700WH one-piece steel surface raceway)
  • UPC: 786776563016
  • Model Number: 5748SWH
  • Type: Raceway Device Box
  • Gang: 1-Gang
  • Profile: Shallow
  • Material: Steel
  • Color: White (Scuffcoat finish)
  • Voltage: 600 Volts
  • Knockout Size: 1/2 in trade size
  • Faceplates: Accepts NEMA single-gang standard faceplates
  • Application: Commercial, Residential
  • Installation Location: On Wall (Indoor)
  • Dimensions: Length: 4.625 in; Width: 2.875 in; Depth: 0.938 in
  • Weight: 0.45 lbs
  • Certifications: cULus Listed (Raceway: File E4376 Guide RJBT; Fittings: File E41751 Guide RJPR), RoHS Compliant
  • Standards: Meets NEC Article 386; Meets CEC Section 12-1600

This Wiremold 5748SWH shallow 1-gang steel raceway device box installs on V500/V700/700WH surface raceways for switch and duplex receptacle applications in residential and commercial settings.
